Służy do wbijania gwoździ papowych w rozmiarze 3,1mm szer., 19 mm – 45mm dł.
Gwoździarka MAX CN445R2
1 975,44 zł
Brutto
Służy do wbijania gwoździ papowych w rozmiarze 3,1mm szer., 19 mm – 45mm dł.
Gwoździarka MAX do płyt okładzinowych i poszycia CN445R2
Cechy:
-
wytrzymała wymienna okrągła końcówka
-
magnes przy końcówce utrzymuje ostatni gwóźdź na miejscu
-
regulacja głębokości wbijania
-
wymienny kontaktor
-
możliwość zdjęcia stopki
-
bezobsługowy filtr tylnej nasadki
Zastosowanie:
-
siding
-
montaż skrzyń
-
łączenie metalu ze sklejką
Specyfikacja:
| model | CN445R2 |
| producent | MAX Japonia |
| waga | 2,4 kg |
| wymiary | 268 (wys.) x 117 (szer.) x 274 (dł.) mm |
| ciśnienie robocze | 5-7 barów |
| pojemność | 120 gwoździ |
| zużycie powietrza | 3l; (0.046ft3)/cykl przy 6 kg/cm2 (90 psi) |
| ID | Kod części | Nazwa części | Cena | Akcja |
|---|---|---|---|---|
| 1 | CN38008 | SCREW M6X25 | 3,40 zł | |
| 2 | CN37853 | PROTECTOR A | 10,75 zł | |
| 3 | CN37191 | CYLINER CAP | 275,35 zł | |
| 4 | CN37855 | CYLINDER CAP SEAL | 26,33 zł | |
| 5 | CN31323 | TRIGGER VALVE HOUSING | 17,01 zł | |
| 6 | CN33723 | Trigger Valve Stem | 9,31 zł | |
| 7 | CN37993 | EXHAUST LABEL | 6,72 zł | |
| 8 | CN37216 | HEAD VALVE GUIDE | 8,95 zł | |
| 9 | CN38003 | O-RING 1AP48 | 4,84 zł | |
| 10 | CN38020 | COMPRESSION SPRING 3934 | 23,28 zł | |
| 11 | KN12644 | O-RING 1AP20 | 1,54 zł | |
| 11 | KN12644 | O-RING 1AP20 | 1,53 zł | |
| 12 | CN37217 | HEAD VALVE PISTON | 14,33 zł | |
| 13 | CN37824 | CYLINDER SEAL | 15,31 zł | |
| 14 | CN38031 | CYLINDER | 438,41 zł | |
| 15 | CN38004 | O-RING 1AG50 | 4,84 zł | |
| 16 | CN37193 | CYLINDER RING | 13,25 zł | |
| 17 | CN38005 | O-RING 1AG75 | 7,97 zł | |
| 18 | CN38006 | O-RING P41 | 4,84 zł | |
| 19 | CN70459 | MAIN PISTON UNIT | 280,18 zł | |
| 20 | CN34714 | BUMPER | 28,56 zł | |
| 21 | CN81237 | FRAME | 623,49 zł | |
| 22 | HH12118 | O-RING 1AG35 | 4,12 zł | |
| 23 | CN81224 | END CAP ASSY (WAS CN37865) | 80,59 zł | |
| 24 | KN12622 | TRIGGER LOCK LEVER | 12,00 zł | |
| 25 | KK23507 | SPRING 3507 | 1,70 zł | |
| 26 | KN12621 | TRIGGER LOCK DIAL | 7,25 zł | |
| 27 | CN31346 | TRIGGER VALVE CAP | 8,06 zł | |
| 28 | KK23735 | COMPRESSION SPRING 3735 | 2,24 zł | |
| 28 | KK23735 | COMPRESSION SPRING 3735 | 2,24 zł | |
| 29 | CN38014 | ROLL PIN 3X32 | 1,88 zł | |
| 30 | CC49408 | NUT 6 | 1,70 zł | |
| 31 | CN37220 | LABEL B CN445R | 21,58 zł | |
| 32 | CN37212 | LABEL A CN445R | 19,97 zł | |
| 33 | KN12643 | O-RING 1AP12 | 1,54 zł | |
| 34 | KN12636 | TRIGGER VALVE HOUSING | 6,22 zł | |
| 34 | KN12636 | TRIGGER VALVE HOUSING | 6,22 zł | |
| 35 | KN12642 | O-RING 1AP6 | 1,08 zł | |
| 35 | KN12642 | O-RING 1AP6 | 1,08 zł | |
| 36 | KN12646 | O-RING 1BP7 | 0,90 zł | |
| 36 | KN12646 | O-RING 1BP7 | 0,90 zł | |
| 37 | CN32246 | PILOT VALVE | 16,83 zł | |
| 38 | KN12641 | O-RING 1AP9 | 1,08 zł | |
| 38 | KN12641 | O-RING 1AP9 | 1,08 zł | |
| 39 | CN38021 | COMPRESSION SPRING 8021 | 1,88 zł | |
| 40 | KN12647 | O-RING 1B 1.4X2.5 | 4,57 zł | |
| 40 | KN12647 | O-RING 1B 1.4X2.5 | 4,57 zł | |
| 41 | CN38030 | TRIGGER VALVE STEM | 38,95 zł | |
| 42 | KN12637 | TRIGGER VALVE CAP | 7,61 zł | |
| 42 | KN12637 | TRIGGER VALVE CAP | 7,61 zł | |
| 43 | CN35115 | CONTACT LEVER | 9,31 zł | |
| 44 | CN35714 | Trigger | 6,98 zł | |
| 45 | FF22402 | SPRING PIN 3X16 (LIGHT LOAD) | 0,90 zł | |
| 45 | FF22402 | SPRING PIN 3X16 (LIGHT LOAD) | 0,90 zł | |
| 46 | KN12660 | STRAIGHT PIN 2660 | 3,40 zł | |
| 46 | KN12660 | STRAIGHT PIN 2660 | 3,40 zł | |
| 47 | CN38027 | ARM GUIDE PIN | 15,31 zł | |
| 48 | KK23129 | COMPRESSION SPRING 3129 | 0,90 zł | |
| 49 | CN37842 | CONTACT ARM GUIDE A | 10,75 zł | |
| 50 | KK23736 | COMPRESSION SPRING 3736 | 3,40 zł | |
| 50 | KK23736 | COMPRESSION SPRING 3736 | 3,40 zł | |
| 51 | KK23653 | COMP. SPRING 3653 | 2,24 zł | |
| 52 | CN35004 | CONTACT BUMPER | 3,40 zł | |
| 52 | CN35004 | CONTACT BUMPER | 3,40 zł | |
| 53 | CN37845 | CONTACT ARM A | 9,31 zł | |
| 54 | CN37210 | ARM COVER | 15,94 zł | |
| 55 | CN38011 | E-RETAINING RING 3.2 | 0,90 zł | |
| 56 | CN37836 | ADJUST DIAL | 24,09 zł | |
| 57 | CN35006 | CONTACT BOLT | 23,73 zł | |
| 58 | CN70456 | CONTACT ARM "B" | 126,70 zł | |
| 60 | CN70450 | CONTACT FOOT UNIT | 242,31 zł | |
| 61 | KK23150 | SPRING 3150 | 4,03 zł | |
| 62 | CN70458 | NOSE UNIT | 1312,63 zł | |
| 63 | CN38001 | O-RING 1AP14 | 1,70 zł | |
| 64 | CN38002 | O-RING 1AP5 | 0,90 zł | |
| 65 | CN38019 | COMPRESSION SPRING 8019 | 3,40 zł | |
| 66 | GN12062 | RUBBER WASHER 2.7X7X2.5 | 3,40 zł | |
| 66 | GN12062 | RUBBER WASHER 2.7X7X2.5 | 3,40 zł | |
| 67 | CN37986 | FEED PAWL | 98,32 zł | |
| 68 | CN38024 | STEP PIN 8024 | 35,64 zł | |
| 69 | CN38022 | FEED PISTON | 83,99 zł | |
| 70 | CN38000 | O-RING 1A P18 | 1,70 zł | |
| 71 | CN37998 | FEED PISTON STOP | 6,72 zł | |
| 72 | CN38016 | COMPRESSION SPRING 8016 | 6,72 zł | |
| 73 | CN37995 | SPRING COLLAR | 14,33 zł | |
| 74 | CN38012 | C-RETAINING RING 24 | 17,01 zł | |
| 75 | CN38023 | STRAIGHT PIN 8023 | 39,94 zł | |
| 76 | CN37994 | CHECK PAWL (WAS IS CN34697) | 18,71 zł | |
| 77 | CN38017 | TORSION SPRING 8017 | 3,40 zł | |
| 78 | CN37988 | DOOR LATCH | 72,35 zł | |
| 79 | CN38018 | COMPRESSION SPRING 8018 | 5,01 zł | |
| 80 | CN38013 | SPRING PIN 3X8 | 0,90 zł | |
| 81 | CN37987 | DOOR | 268,63 zł | |
| 82 | CN38025 | STEP PIN 8025 | 43,97 zł | |
| 83 | CN37863 | MAGAZINE CAP | 39,94 zł | |
| 84 | CN31458 | MAGAZINE WEAR CLIP | 4,75 zł | |
| 85 | CN37428 | Post Cap | 6,72 zł | |
| 86 | CN37823 | NAIL SUPPORT | 15,67 zł | |
| 87 | EE31104 | PLAIN WASHER 1-6 | 0,90 zł | |
| 88 | FF22203 | W.S. PIN 4X40(FORMER FF21222) | 2,24 zł | |
| 89 | CN37862 | MAGAZINE | 67,96 zł | |
| 90 | CN30601 | SPACER CN65091 | 3,22 zł | |
| 91 | CN38015 | TENSION SPRING 8015 | 6,72 zł | |
| 92 | CN37383 | SPRING HOOK | 6,18 zł | |
| 93 | CN37829 | SHINGLE GAUGE | 22,39 zł | |
| 94 | EE11101 | SPRING WASHER 2-6 | 0,90 zł | |
| 95 | CN38007 | SCREW M6X22 | 3,40 zł | |
| 96 | CN37206 | FRAME HANGER | 812,25 zł | |
| 97 | BB40422 | BOLT 6X30 FOR CC00402 | 1,70 zł | |
| 98 | CN37991 | CHECK VALVE | 11,01 zł | |
| 99 | CN35140 | CONTACT ARM A | 34,74 zł | |
| 100 | KK23282 | COMPRESSION SPRING 3282 | 2,51 zł | |
| 101 | KK33247 | SPRING 3247 | 11,01 zł | |
| 102 | TA16138 | S.T. LEVER | 55,07 zł | |
| 103 | KK33144 | TORSION SPRING 3144 | 11,01 zł | |
| 104 | CN35714 | TRIGGER | 6,98 zł | |
| 105 | CN35128 | TRIGGER VALVE STEM | 12,00 zł | |
| 106 | CN34500 | SPRING, LEVER | 10,30 zł | |
| 107 | CN35001 | TRIGGER | 6,98 zł | |
| 108 | CN35002 | ARM GUIDE | 10,30 zł | |
| 109 | CN35003 | CONTACT ARM A | 4,75 zł | |
| 110 | TA17024 | FILTER A | 38,95 zł | |
| 111 | CN37208 | CN37853 REPLACED PROTECTOR B | 18,18 zł | |
| 112 | CN38010 | SCREW M6X12 | 4,84 zł | |
| 113 | CN37211 | ADJUST SPACER | 9,49 zł | |
| 114 | CN38009 | SCREW M8X30 | 4,84 zł | |
| 116 | CN37992 | O-RING A1.2X4 | 1,70 zł | |
| 118 | 4009571 | CAUTION LABEL | 5,64 zł | |
| 119 | CN35656 | LEVER | 6,98 zł | |
| 120 | CN37204 | CONTACT BOLT | 420,95 zł | |
| 201 | CN81250 | TRIGGER VALVE KIT | 77,28 zł | |
| 202 | CN81251 | ARM GUIDE KIT | 50,06 zł | |
| 203 | CN81156 | FRAME HANGER ASSY (CN445R) | 795,60 zł | |
| 205 | CN81252 | S.T. KIT | 246,60 zł | |
| 206 | CN81253 | O-RING KIT ASSY | 82,83 zł | |
| 207 | CN81254 | ANTI-DOUBLE FIRE TRIGGER KIT | 785,75 zł |
