Gwoździarka MAX CN890S
Służy do wbijania gwoździ z łbem płaskim połączonych drutem oraz gwoździ połączonych taśmą plastikową,
w rozmiarze 2,5 mm - 3,8 mm szer., 45 mm - 90 mm dł.
Gwoździarka bębnowa MAX do konstrukcji szkieletowych CN890S
Cechy:
-
waży zaledwie 3,3 kg
-
mechanizm zapobiegający przypadkowemu wystrzeleniu kolejnego gwoździa (Patent USA 5597106, Patent UK 2286790)
-
służy do wbijania gwoździ połączonych zarówno drutem jak i taśmą plastikową
-
regulacja głębokości wbijania
-
spiczaste zęby na ramieniu stykowym gwarantują pewne przyłożenie podczas ukośnego wbijania gwoździ
-
miękka końcówka dla zabezpieczenia miękkich materiałów przed pozostawieniem śladu wokół wbitego gwoździa
-
możliwość swobodnego obracania narzędzia
-
wygodna rączka pokryta gumą
-
konfigurowalny deflektor odprowadzanego powietrza
-
bezobsługowy filtr tylnej nasadki (Patent USA 5637125, Patent UK 2294412, Patent niemiecki 19539950.1)
Zastosowanie:
-
konstrukcje szkieletowe
-
poszycia
-
podesty
-
podkłady podłogowe
-
podesty zewnętrzne
-
obkładanie
-
siding
-
montaż skrzyń
Specyfikacja:
model | CN890S |
producent | MAX Japonia |
waga | 3,3 kg |
wymiary | 387 (wys.) x 129 (szer.) x 331 (dł.) mm |
ciśnienie robocze | 5-7 barów |
pojemność |
350 gwoździ połączonych drutem |

ID | Kod części | Nazwa części | Cena | Akcja |
---|---|---|---|---|
1 | AA82411 | Screw M6 x 20 | 2,07 zł | |
2 | KN11393 | EXHAUST COVER HOLDER | 17,31 zł | |
3 | CN35294 | EXHAUST COVER | 40,11 zł | |
4 | CN35295 | Exhaust Filter "A" | 56,60 zł | |
5 | KN11392 | Exhaust Filter "B" (repl. CN35296) | 15,14 zł | |
6 | BB40208 | Screw M6 x 28 | 3,15 zł | |
7 | CN35635 | Protector | 12,62 zł | |
8 | KN70016 | Cylinder Cap Unit (repl. CN35292) | 229,57 zł | |
9 | CN35298 | Cylinder Cap Seal | 55,98 zł | |
10 | CN35323 | Plain Washer | 2,79 zł | |
11 | KK23713 | Compression Spring 3713 | 11,72 zł | |
12 | HH14906 | O-Ring AS568-133 | 7,31 zł | |
13 | KN11391 | Head Valve Piston (repl. CN35839) | 154,32 zł | |
14 | HH19161 | O-Ring 1 A 3.1 X 66.4 | 7,66 zł | |
15 | CN35307 | Heaad Valve Seal | 26,76 zł | |
16 | CN35334 | Plain Washer | 7,66 zł | |
17 | CN35302 | Piston Stop | 32,18 zł | |
18 | CN35306 | Cylinder | 178,46 zł | |
19 | HH12108 | O-Ring 1AG65 | 7,31 zł | |
20 | CN35325 | Check Valve | 14,87 zł | |
21 | CN35308 | Cylinder Ring | 25,95 zł | |
22 | HH12117 | O-Ring 1AG85 | 6,22 zł | |
23 | HH19218 | O-Ring 4.5 x 48.8 | 24,34 zł | |
24 | CN35639 | Main Piston Unit | 300,42 zł | |
25 | CN35841 | Frame (replaces CN35291) | 484,93 zł | |
26 | CN35636 | Warning Label (Frame) | 5,14 zł | |
27 | CN35075 | Trigger Lock Lever (replaces CN35057) | 3,69 zł | |
28 | CN35331 | End Cap Seal | 53,71 zł | |
29 | TT05426 | Swivel Joint | 194,24 zł | |
30 | BB40210 | Screw M5x20 | 2,08 zł | |
31 | CN35686 | End Cap (repl. CN35631) | 93,11 zł | |
32 | BB40438 | Screw M6x32 | 1,53 zł | |
35 | KK23507 | Compression Spring 3507 | 1,54 zł | |
33 | CN34309 | Label, Plastic Sheet | 5,23 zł | |
36 | CN35074 | Tigg.Lock Dial/repCN35058 | 3,60 zł | |
37 | FF21611 | Roll Pin 3 x 32 AW | 1,54 zł | |
38 | HH11105 | O-Ring AP7 | 1,54 zł | |
39 | HH11125 | O-Ring 1AP12 | 1,54 zł | |
40 | HH11138 | O-Ring 1AP20 | 2,08 zł | |
41 | CN33909 | Trigger Valve Housing | 13,35 zł | |
42 | FF30161 | Straight Pin 161 | 2,08 zł | |
43 | HH11119 | O-Ring 1AP6 | 1,54 zł | |
44 | HH11209 | O-Ring 1BP7 | 2,08 zł | |
45 | CN35655 | Pilot Valve | 12,62 zł | |
46 | HH11113 | O-Ring 1AP9 | 1,54 zł | |
47 | CN31436 | Pilot Orifice | 7,31 zł | |
48 | KK24123 | Compression Spring 4123 | 4,06 zł | |
49 | CN35128 | Trigger Valve Stem | 11,08 zł | |
50 | HH11901 | O-Ring 1B1.4x2.5 | 1,54 zł | |
51 | CN33910 | Trigger Valve Cap | 7,31 zł | |
52 | CN35115 | Contact Lever | 8,65 zł | |
53 | CN35001 | Trigger | 3,69 zł | |
54 | FF22402 | Spring Pin 3x16 | 0,90 zł | |
55 | KK23282 | Compression Spring 3282 | 2,35 zł | |
56 | CN35656 | Lever | 3,69 zł | |
57 | CN34500 | Spring Lever | 9,46 zł | |
58 | CN35059 | Contact Arm Guide B | 18,47 zł | |
59 | CN35002 | Arm Guide | 9,46 zł | |
60 | KK23735 | Compression Spring 3735 | 2,07 zł | |
61 | KK23736 | Compression Spring 3736 | 3,15 zł | |
62 | CN35004 | Contact Bumper | 3,15 zł | |
63 | CN35003 | Contact Arm A | 4,33 zł | |
64 | CN35327 | Bumper | 42,36 zł | |
65 | HH14729 | O-Ring AS568-144 | 8,65 zł | |
66 | CN35312 | Nose | 1235,83 zł | |
67 | BB40221 | Screw M8 x 25 | 3,15 zł | |
68 | EE39602 | Rubber Washer 7 (replaces EE39621) | 1,53 zł | |
69 | HN10477 | Latch A (replaces CN35330) | 43,17 zł | |
70 | FF41258 | PIN 1258 | 11,72 zł | |
71 | FF41599 | Step Pin 1599 | 8,65 zł | |
72 | CN35315 | Door | 349,63 zł | |
73 | KK33261 | Torsion Spring 3261 (repl. KK33169) | 2,08 zł | |
74 | CN33679 | Door Latch | 41,01 zł | |
75 | CN31083 | Dust Cover Hook | 1,54 zł | |
76 | EE39609 | Rubber Washer 1.8x6x2 | 1,54 zł | |
77 | FF31520 | Straight Pin 1520 | 8,65 zł | |
78 | FF31272 | Straight Pin 1272 | 7,31 zł | |
79 | CN37836 | Adjust Dial | 22,26 zł | |
80 | CN35337 | Contact Arm "C" | 29,93 zł | |
81 | HH11903 | O-Ring 1A1,2x4 | 2,08 zł | |
82 | KK23792 | Comp.Spring 3792 | 4,06 zł | |
83 | JJ10404 | E-Ring 3.2 | 0,90 zł | |
84 | CN70048 | Contact Arm B Unit (repl. CN35310) to be used with CN35899, KK23792 and KK23793 | 168,46 zł | |
85 | CN36130 | Contakt Tip (replaces CN35339) | 18,84 zł | |
86 | CN35899 | Adjust Spacer (repl. CN35309) to be used with CN70048, KK23792 and KK23793 | 10,18 zł | |
87 | CN35632 | Cover | 28,30 zł | |
88 | CC00402 | Elastic Stop Nut M6x1 | 2,08 zł | |
89 | CN35336 | Ceck Pawl (replaces CN33336) | 7,31 zł | |
90 | KK33221 | Torsion Spring 3221 | 7,31 zł | |
91 | KK23626 | Compression Spring 3626 | 5,14 zł | |
92 | HN10476 | Feed Pawl (was CN35313) | 142,78 zł | |
93 | FF42216 | Step Pin 2216 | 14,87 zł | |
94 | HH11132 | O-Ring 1AP10A | 1,54 zł | |
95 | CN35314 | Feed Piston | 64,45 zł | |
96 | HH11143 | O-Ring 1AP21 | 3,15 zł | |
97 | KK23737 | Compression Spring 3737 | 6,22 zł | |
98 | KK23225 | Compression Spring 3225 | 2,08 zł | |
99 | CN37528 | Feed Piston Stop | 4,69 zł | |
100 | CN37538 | Spring Collar | 13,35 zł | |
101 | JJ22407 | Retaining Ring C26 | 3,87 zł | |
102 | CN35651 | Magazine Cover | 41,01 zł | |
103 | CN34879 | Warning Label (Magazine) | 7,31 zł | |
104 | CN37428 | Post Cap | 5,85 zł | |
105 | CN35317 | Magazine | 65,89 zł | |
106 | CN35318 | Nail Support | 19,74 zł | |
107 | CN35340 | Magazine Wear Clip | 8,65 zł | |
108 | CN30601 | Spacer | 1,54 zł | |
109 | KK13144 | Tension Spring 3144 | 4,06 zł | |
110 | CN37383 | Receiver, Spring | 3,42 zł | |
111 | FF41287 | Step Pin 1287 | 5,14 zł | |
112 | CN35322 | Dust Cover | 14,15 zł | |
113 | BB40211 | Bolt 6 x 35 | 6,22 zł | |
114 | EE33111 | Plain Washer 6 | 0,90 zł | |
115 | CN35642 | Hanger | 194,16 zł | |
117 | CN35641 | Special Nut | 28,49 zł | |
118 | BB40411 | Screw M6x20 | 1,54 zł | |
119 | CN35644 | Contact Arm C Unit | 809,40 zł | |
120 | CN31323 | Trigger Valve Hausing | 15,68 zł | |
121 | CN35655 | Pilot Valve | 12,62 zł | |
122 | KK24123 | Compression Spring 4123 | 4,06 zł | |
123 | CN33723 | Trigger Valve Stem | 8,65 zł | |
124 | CN31346 | Trigger Valve Cap | 7,31 zł | |
125 | KK33247 | Torsion spring 3247 (replaces KK33145) | 9,46 zł | |
126 | TA16138 | S.T. Lever (replaces CN33730) | 46,24 zł | |
127 | KK33144 | Torsion Spring 3144 | 10,18 zł | |
128 | CN35071 | Trigger | 9,91 zł | |
129 | CN35139 | Contact Arm Guide C | 9,37 zł | |
131 | CN35140 | Contact Arm A | 32,18 zł | |
132 | CN35681 | Label B | 5,95 zł | |
133 | KK23793 | Comp.Spring 3793 | 4,06 zł | |
134 | KK23788 | Compression Spring 3788 | 3,42 zł | |
135 | CN35685 | End Cap Filter (to be used with end cap CN35686) | 46,78 zł | |
6 | BB40208 | Screw M6 x 28 | 3,15 zł | |
7 | CN35635 | Protector | 12,62 zł | |
32 | BB40438 | Screw M6x32 | 1,53 zł | |
39 | HH11125 | O-Ring 1AP12 | 1,54 zł | |
40 | HH11138 | O-Ring 1AP20 | 2,08 zł | |
42 | FF30161 | Straight Pin 161 | 2,08 zł | |
43 | HH11119 | O-Ring 1AP6 | 1,54 zł | |
44 | HH11209 | O-Ring 1BP7 | 2,08 zł | |
46 | HH11113 | O-Ring 1AP9 | 1,54 zł | |
48 | KK24123 | Compression Spring 4123 | 4,06 zł | |
50 | HH11901 | O-Ring 1B1.4x2.5 | 1,54 zł | |
54 | FF22402 | Spring Pin 3x16 | 0,90 zł | |
58 | CN35059 | Contact Arm Guide B | 18,47 zł | |
60 | KK23735 | Compression Spring 3735 | 2,07 zł | |
48 | KK24123 | Compression Spring 4123 | 4,06 zł | |
61 | KK23736 | Compression Spring 3736 | 3,15 zł | |
62 | CN35004 | Contact Bumper | 3,15 zł | |
68 | EE39602 | Rubber Washer 7 (repl. EE39621) | 1,54 zł | |
68 | EE39602 | Rubber Washer7/repEE39621 | 1,54 zł | |
76 | EE39609 | RUBBER WASHER 1.8X6X2 | 1,54 zł | |
89 | CN35336 | Ceck Pawl (replaces CN33336) | 7,31 zł | |
75 | CN31083 | Dust Cover Hook | 1,54 zł | |
68 | EE39602 | RUBBER WASHER 7 | 1,54 zł | |
90 | KK33221 | Torsion Spring 3221 | 7,31 zł | |
88 | CC00402 | Elastic Stop Nut M6x1 | 2,08 zł |
