Służy do wbijania kołków do betonu w różnych rozmiarach – od15mm x Ø 2.6mm / 20mm x Ø 2.1mm do 40mm x Ø 2.6mm, połączonych plastikową taśmą.
Gwoździarka MAX GS738C LT
3 842,52 zł
Brutto
Służy do wbijania kołków do betonu w różnych rozmiarach – od15mm x Ø 2.6mm / 20mm x Ø 2.1mm do 40mm x Ø 2.6mm, połączonych plastikową taśmą.
Gwoździarka gazowa MAX GS738C LT
Cechy:
-
Możliwość dostosowania głębokości
-
Łatwy dostęp do rogów
-
Proste usuwanie zatorów
-
Ultra lekki spust – waży zaledwie 1,2 kg
-
Filtry siatkowe ze stali nierdzewnej
-
Proste ładowanie kołków
-
Łatwość wkładania akumulatora
-
Miękki uchwyt
-
Dioda informująca o niskim poziomie naładowania akumulatora
-
Konfigurowalny hak na pasek
Zastosowanie:
-
Mocowanie łączników do podłogi
-
Mocowanie prowadnic drewnianych do podłogi
-
Mocowanie prowadnic do sufitu
-
Mocowanie elementów stalowych do podłogi
-
Mocowanie ożebrowania ścian z płyt gipsowych do betonu
-
Mocowanie listew
Specyfikacja:
| model | GS738C LT |
| waga | 3,7 kg |
| wymiary | 365(Wys.) x 124(Szer.) x 435(Dł.) mm |
| pojemność | 42 gwoździe |
| bateria | akumulator |
| rodzaj akumulatora | Niklowo-metalowo-wodorkowa 6 V DC 1.5 Ah |
| czas ładowania | max. 150 minut |
| źródło zasilania | 100-240V AC, 50 lub 60Hz |
| Pobór mocy | 8VA(10V 800mA) (wyjście znamionowe) |
| rodzaj gwoździ | 2,6 mm x 15 - 40 mm |
| ID | Kod części | Nazwa części | Cena | Akcja |
|---|---|---|---|---|
| 1 | BB40408 | BOLT 5X14 | 1,70 zł | |
| 2 | EE39172 | WASHER 5.1X12X1.2 | 7,61 zł | |
| 3 | GN70293 | CYLINDER CAP UNIT | 90,08 zł | |
| 4 | GN12053 | RETAINING RING C TYPE | 1,25 zł | |
| 5 | GN11844 | PLAIN WASHER | 1,61 zł | |
| 6 | GN11849 | MOTOR MOUNT L | 5,01 zł | |
| 7 | GN12051 | MOTOR SLEEVE | 9,85 zł | |
| 8 | GN70177 | MOTOR UNIT C5-C1 | 449,60 zł | |
| 9 | GN10026 | WASHER | 2,60 zł | |
| 10 | GN10448 | MOTOR MOUNT S | 5,64 zł | |
| 11 | GN80036 | PLUG ASSY | 69,93 zł | |
| 12 | GN12140 | CYLINDER HEAD C5 | 78,62 zł | |
| 13 | GN70001 | FAN UNIT | 45,04 zł | |
| 14 | AA74403 | SCREW 4 X 5 | 0,90 zł | |
| 15 | GN12141 | RUBBER TUBE | 14,33 zł | |
| 16 | GN11818 | TUBE FITTING M5 | 5,01 zł | |
| 17 | HH14036 | O-RING AS 563-036 | 8,06 zł | |
| 18 | AA01703 | SCREW 4X8 | 1,08 zł | |
| 19 | GN11819 | CONNECTER HOLDER | 3,94 zł | |
| 20 | GN11820 | COMP. SPRING (CHAMBER) | 1,70 zł | |
| 21 | GN11822 | GUIDE POLE | 185,27 zł | |
| 22 | GN11821 | O-RING 4D 3.5X75.8 | 46,92 zł | |
| 23 | GN11488 | UPPER CHAMBER | 327,19 zł | |
| 24 | GN11823 | SEAL PLATE | 216,25 zł | |
| 25 | GN12092 | LOWER CHAMBER | 431,96 zł | |
| 26 | GN12072 | HEXAGON SOCKETHEAD CA | 0,90 zł | |
| 27 | GN12194 | CHAMBER ARM | 12,09 zł | |
| 28 | GN11485 | CHMBER PLATE | 188,76 zł | |
| 29 | GN10221 | RETAINING RING | 15,04 zł | |
| 30 | GN70320 | MAIN PISTON UNIT | 208,55 zł | |
| 31 | GN10224 | PISTON RING | 49,25 zł | |
| 32 | GN11546 | BUMPER | 43,43 zł | |
| 33 | GN11496 | CYLINDER | 365,70 zł | |
| 34 | GN11494 | BUFFER PLATE | 3,40 zł | |
| 35 | GN11491 | VALVE BASE | 10,66 zł | |
| 36 | GN11824 | REED VALVE SEAL | 5,01 zł | |
| 37 | GN11493 | REED VALVE | 3,40 zł | |
| 38 | GN11495 | VALVE FILTER | 4,30 zł | |
| 39 | GN11492 | VALVE COVER | 14,33 zł | |
| 40 | BB40456 | BOLT 5X8 | 1,70 zł | |
| 41 | GN12185 | HEXAGON NUT WITH NYLON | 3,40 zł | |
| 42 | CC49508 | NUT M5 | 1,70 zł | |
| 43 | GN70290 | HANDLE R UNIT | 83,99 zł | |
| 44 | GN11501 | CHAMBER ARM GUIDE | 8,06 zł | |
| 45 | GN12145 | BODY | 63,58 zł | |
| 46 | GN12073 | HEXAGON NUT WITH FLANG | 1,61 zł | |
| 47 | GN12135 | HOLLOW SHAFT 7.2X33.5 | 21,31 zł | |
| 48 | GN12133 | HEXAGON SOCKET HEAD | 3,40 zł | |
| 49 | HH11114 | O-RING AP4 N10094 | 1,70 zł | |
| 50 | GN11828 | COMP. SPRING | 0,90 zł | |
| 51 | GN12060 | STEEL BALL 3 | 0,90 zł | |
| 52 | GN11830 | MAGAZINE BUFFER | 3,40 zł | |
| 53 | GN11524 | NOSE(C5) | 356,30 zł | |
| 54 | BB40428 | SCREW 6MM X 25MM | 1,70 zł | |
| 55 | GN11829 | NOSE TOP (C5) | 151,42 zł | |
| 56 | GN12055 | CONTACT BUMPER | 3,49 zł | |
| 57 | GN12136 | HOLLOW SHAFT 7.2X47 | 27,13 zł | |
| 58 | GN70241 | BODY COVER UNIT | 79,69 zł | |
| 59 | GN12082 | HEXAGON SOCKET HEAD CA | 0,90 zł | |
| 60 | GN11827 | ADJUST DIAL C5 | 3,40 zł | |
| 61 | GN11525 | SCREW ROD | 43,97 zł | |
| 62 | GN11527 | ARM BUSHING | 13,07 zł | |
| 63 | GN11526 | CONTACT ARM B | 22,92 zł | |
| 64 | GN11848 | ARM WASHER | 2,51 zł | |
| 65 | GN11528 | ARM NUT | 20,42 zł | |
| 66 | HH19722 | O-RING A1.5X5 | 2,24 zł | |
| 67 | GN11520 | CONTACT ARM C | 66,62 zł | |
| 68 | GN12159 | HEXAGON SOCKET BUTTON HEAD SCREW 4X18 | 22,92 zł | |
| 69 | GN12152 | FUEL CAP B | 27,13 zł | |
| 70 | GN12153 | FUEL LATCH | 26,06 zł | |
| 71 | GN12163 | COMPRESSION SPRING (LATCH) | 6,98 zł | |
| 72 | GN12154 | PARALLEL PIN (CAP) | 6,27 zł | |
| 73 | GN12151 | FUEL CAP A | 29,64 zł | |
| 75 | GN12162 | CORN SPRING(FUEL CAP) | 17,55 zł | |
| 77 | GN12160 | HEXAGON NUT WITH FLANG | 2,78 zł | |
| 78 | GN70309 | F-COVER SW UNIT-N | 45,04 zł | |
| 79 | AA05544 | TAP TIGHT(P) 3X12 | 0,90 zł | |
| 80 | GN12157 | FUEL SW LEVER | 6,72 zł | |
| 81 | GN12165 | COMP. SPRING | 5,01 zł | |
| 82 | GN70314 | SOLENOID VALVE ASSY-N | 530,91 zł | |
| 83 | GN12149 | PIPE COVER | 5,01 zł | |
| 84 | GN11592 | FAN SW LEVER | 3,40 zł | |
| 85 | GN70308 | FAN SW UNIT C5-N | 45,04 zł | |
| 86 | GN12131 | CONTACT ARM A | 21,31 zł | |
| 87 | GN70318 | F-CELL CONNECTION ASSY | 145,51 zł | |
| 88 | GN12059 | ADJUST STOPPER | 2,15 zł | |
| 89 | GN12081 | BODY COVER BUSH | 5,55 zł | |
| 90 | GN11991 | NAME LABEL(GS738C LT CE) | 9,31 zł | |
| 91 | GN11997 | WARNING LABEL | 9,31 zł | |
| 92 | GN11588 | COMPRESSION SPRING (STOPPER) | 2,15 zł | |
| 93 | GN70351 | CONNECTION CODE UNIT | 8,56 zł | |
| 94 | GN12088 | VATTERY PROTECTOR | 2,60 zł | |
| 95 | GN70306 | CONTROL UNIT C5 | 445,30 zł | |
| 96 | GN12192 | FUEL SIDE COVER | 14,86 zł | |
| 97 | GN12138 | PARALLEL PIN 3X27.2 | 5,91 zł | |
| 98 | GN70190 | TRIGGER ASSEMBLY KIT includes (98,100,101,102,104) | 32,31 zł | |
| 99 | GN12146 | CHAMBER LOCK BAR | 6,72 zł | |
| 100 | GN70190 | TRIGGER ASSEMBLY KIT includes (98,100,101,102,104) | 32,31 zł | |
| 101 | GN70190 | TRIGGER ASSEMBLY KIT includes (98,100,101,102,104) | 32,31 zł | |
| 102 | GN70190 | TRIGGER ASSEMBLY KIT includes (98,100,101,102,104) | 32,31 zł | |
| 103 | GN11596 | TRIGGER SPRING | 1,61 zł | |
| 105 | GN70179 | TRIGGER SW UNIT C5 | 46,65 zł | |
| 106 | GN11593 | COMP. SPRING | 0,90 zł | |
| 107 | GN10058 | ELECTRODE PLATE | 5,91 zł | |
| 108 | AA01106 | SCREW 3X6 WITH WASHER | 0,90 zł | |
| 109 | GN10059 | ELECTRODE BLOCK | 7,61 zł | |
| 110 | GN80165 | BATTERY ASSY | 158,05 zł | |
| 111 | GN12168 | LATCH B | 7,88 zł | |
| 112 | GN11508 | TRIGGER SW LEVER | 1,88 zł | |
| 113 | GN11540 | REMOVE ARM | 5,91 zł | |
| 114 | GN11539 | REMOVE FRAME | 4,75 zł | |
| 115 | GN11537 | REMOVE LEVER | 3,40 zł | |
| 116 | GN11541 | REMOVE GUIDE | 3,40 zł | |
| 117 | GN11815 | COMP. SPRING | 2,60 zł | |
| 118 | FF31572 | PIN 1572 | 3,40 zł | |
| 119 | GN70292 | HANDLE L UNIT | 101,54 zł | |
| 120 | GN12132 | BELT HOOK | 23,28 zł | |
| 121 | GN12137 | HEXAGON SOCKET HEAD | 1,61 zł | |
| 122 | GN11542 | REMOVE COVER | 4,12 zł | |
| 123 | GN12184 | HEXAGON SOCKET HEAD CAP SCREW 4X20 EP | 2,15 zł | |
| 124 | GN12068 | CROSS RECESSED HEAD TA | 0,90 zł | |
| 125 | GN11583 | MAGAZINE STOPPER | 4,75 zł | |
| 126 | GN11589 | PARALLEL PIN (STOPPER) | 10,66 zł | |
| 127 | KN12419 | NAIL STOPPER | 11,28 zł | |
| 128 | GN12070 | RUBBER WASHER 1.7X6X2 | 2,69 zł | |
| 129 | GN12186 | MAGAZINE FOOT C5 | 33,94 zł | |
| 130 | GN11582 | MAGAZINE HUNGER | 38,95 zł | |
| 131 | GN11871 | MAGAZINE 38L | 503,95 zł | |
| 132 | GN11872 | MAGAZINE COVER 38 | 19,34 zł | |
| 133 | GN12061 | SPRING STOPPER | 3,40 zł | |
| 134 | GN12063 | SPRING COVER A | 3,40 zł | |
| 135 | GN12067 | CONSTANT FORCE SPRING | 34,74 zł | |
| 136 | GN12065 | SPRING COLLAR | 3,40 zł | |
| 137 | GN12064 | SPRING COVER B | 3,40 zł | |
| 138 | GN11531 | FOLLOWER HOLDER | 10,66 zł | |
| 139 | GN12066 | COMP. SPRING (FOLLOWER) | 2,15 zł | |
| 140 | GN12062 | RUBBER WASHER 2.7X7X2.5 | 3,40 zł | |
| 141 | GN11530 | FOLLOWER C5 | 23,19 zł | |
| 142 | GN11591 | PARALLEL PIN (FOLLOWER) | 11,55 zł | |
| 143 | GN11580 | ANTIFIRE PLATE | 5,64 zł | |
| 144 | GN11590 | SQUARE NUT M5 | 0,90 zł | |
| 145 | GN12069 | HEXAGON SOCKET HEAD CA | 0,90 zł | |
| 146 | GN12148 | FUEL PIPE | 65,28 zł | |
| 147 | GN12087 | COMP. SPRING (CTA-A) | 6,72 zł | |
| 148 | GN12134 | HEXAGON SOCKET HEAD | 5,55 zł | |
| 150 | GN70350 | POWER CORD HARNESS NUIT | 7,70 zł | |
| 151 | GN70368 | Charger Base | 304,99 zł | |
| 152 | GN80184 | ADAPTER ASSY | 151,15 zł | |
| 154 | GN12180 | SCREW COVER | 14,33 zł | |
| 155 | GN11855 | LOWER PLATE | 12,98 zł |
